Hp1 Fram Engine Oil Filter

Country Of Origin: U.S.A.
Quantity in Basket: None
Part Number: ac115802

Price: $32.50

Sold As: 1 Fram Hp1 Oil Filter
Mfg UPC: 009100752307

Quantity:

FRAM HP1 Oil Filter Specifications

Oil Filter Style: Canister
Height: 5.750 inches
Outside Diameter: 3.719 inches
Filter Bypass Relief Valve: Yes
Relief Valve Open: 22 psi
Anti-Drainback Valve: Yes
Smallest Particle Filtered: 18 microns
Maximum Burst Pressure: 500 psi
Thread Size: 3/4-16
Gasket Outside Diameter: 2.813 inches
Gasket Inside Diameter: 2.422 inches
Gasket Thickness: 0.328 inches

California Prop 65 Warning: This item may cause cancer or reproductive harm. For more info visit p65warnings.ca.gov The above image is a representation of this item. Actual item may vary.
