Holley Red Electric Fuel Pump For Carbureted Engines 97 Gph Maximum Pressure Is 7 Psi

Holley Red Electric Fuel Pump For Carbureted Engines 97 Gph Maximum Pressure Is 7 Psi
    Quantity in Basket: None
    Part Number: holley12-801-1
    Price: $157.75
    Sold As: 1 Holley Red Electric Fuel Pump
    Mfg UPC: 12-801-1



    Quantity:

    Proven winners over the years thanks to their lightweight design (2.88 lbs) and ability to tolerate contaminated fuel, these Holley fuel pumps are powered by a long-life, heavy-duty, sealed-dry motor. They have a relief valve for pressure compensation and washable inlet filter screen that cleans fuel as it travels between the 3/8" inlet and outlet ports in the aluminum housing. Redesigned flow passages improve durability, reduce amp draw, and eliminate pulsation, which provides a higher, more consistent flow.

    Features
    Maximum Pressure Is 7 PSI
    Motor Draws 2 Amps Current
    7.5 Amp fuse recommended
    Constant Fuel Flow with No Pulsation
    Flows 97 GPH (free flow)
    Flows 71 GPH at 4 PSI
    Has externally accessible pressure relief valve (max 7 PSI)
    Rotor/Vane pump design is more tolerant of contaminated fuels
    Weighs only 2.88 lbs
    Includes mounting bracket
    Repair kits are readily available
    Can be serviced from the pump end
    NOT compatible with alcohol or methanol fuels
    Not designed or recommended for use with fuel injection systems
