Blue Sea M-Series Black Battery Cut Off Isolator Switch With Removeable Knob For A Single Battery

Blue Sea M-Series Black Battery Cut Off Isolator Switch With Removeable Knob For A Single Battery
    Quantity in Basket: None
    Part Number: bluesea6006200
    Price: $40.00
    Sold As: One Battery On-Off Switch
    Mfg UPC: 6006200



    Quantity:

    K-Four Switches Cross Reference 16-125

    m-Series Mini On-Off Battery Switch with Knob - Black

    PN 6006200
    • Ignition protected—safe for installation aboard gasoline powered Sand Rails, Dune Buggies, Manx Buggies, UTV, Side-X-Sides, Trucks, Jeeps, or Rock Crawlers
    • Case design allows surface, front panel, or rear panel mounting
    • Isolating cover with snap-on sections protects rear contacts


    Specifications
    Switch Type Single Circuit ON-OFF
    Color Black
    Switch Positions 2
    Battery Combine No
    Alternator Field Disconnect No
    Maximum Voltage 48V DC
    Continuous Rating 300A
    Intermittent Rating 500A (5 min)
    Cranking Rating 10 sec 1500A
    Cranking Rating 1 min 775A
    Battery Inputs 1
    Cable Clearance For 4/0 AWG Cables 1.12in (28.45 mm)
    Cable Size to Meet Ratings 4/0 AWG (120mm²)
    Mounting Holes Accept #10 Screw
    Terminal Stud Size 3/8"-16 (M10)
    Terminal Stud Torque 120 in-lb (13.56 Nm)
    Weight 0.65lb (0.29 kg)
