Heim Joint 3/8-24 Right Hand Thread With 3/8 Hole For Adjustable Light Bar Tie Rods

Heim Joint 3/8-24 Right Hand Thread With 3/8 Hole For Adjustable Light Bar Tie Rods
    Quantity in Basket: None
    Part Number: ac941602r
    Price: $4.75
    Sold As: Heim Joint


    Quantity:


    Economy CM 2 Piece Metal to Metal Heim Joint Specs

    Economy CM 2 Piece Metal to Metal Specs MATERIALS
    BALL BODY
    52100 STEEL LOW CARBON STEEL
    Rc 56 MIN. ZINC PLATED
    HARD CHROME PLATED CHROMATE TREATED
    Part #'s B
    Dia.
    +.0025
    -.0005
    D
    Dia.
    +.010
    -.010
    W
    Width
    +.005
    -.005
    T
    Width
    Ball
    Dia.
    A
    Length
    +.015
    -.015
    N
    Thread
    .UNF 3A
    C
    Length
    +.062
    -.031
    Angle in Degrees if mounted in a clevis or between 2 tabs without misalignment shims ULT. Static
    Radial Load (lbs.)
    Approx.
    Weight (lbs.)
    FKCM 3 .1900 .625 .312 .234 .437 1.250 10-32 .750 20 1,210 .03
    FKCM 4 .2500 .750 .375 .250 .500 1.562 1/4-28 1.000 27 2,225 .04
    FKCM 5 .3125 .875 .437 .312 .625 1.875 5/16-24 1.250 22 3,600 .07
    FKCM 6 .3750 1.000 .500 .359 .719 1.938 3/8-24 1.250 22 5,100 .11
    FKCM 7 .4375 1.125 .562 .406 .812 2.125 7/16-20 1.375 21 6,402 .15
    FKCM 8 .5000 1.312 .625 .453 .937 2.438 1/2-20 1.500 20 8,386 .24
    FKCM 10 .6250 1.500 .750 .484 1.125 2.625 5/8-18 1.625 26 9,813 .36
    FKCM 12 .7500 1.750 .875 .593 1.312 2.875 3/4-16 1.750 24 14,290 .57
