MSD 6AL IGNITION CONTROL BOX
	Quantity in Basket: None Code: MSD6420 Price: $285.00 Parts In Set: EACH
	Quantity:
MSD 6AL, PN 6420 The 6AL shares the same proven circuitry of the 6A with the addition of a built-in adjustable rev limiter. The combination of powerful sparks with the safety of a Soft Touch Rev Control is what makes the 6AL the most popular ignition control in the world. MSD first developed the Soft Touch rev control to prevent overrev damage to your motor in the event of a missed shift or driveline failure. The rpm limit is adjustable in 100 rpm increments with MSD's plug-in modules. When the engine reaches your selected limit, the Soft Touch circuitry begins dropping the spark to various cylinders. On the next cycle, these plugs are fired again to prevent fuel from loading up in the cylinder. The result is a smooth and accurate limiting action without backfires or roughness. The Soft Touch Rev Control also opens the door for you to add rpm accessories such as a Two Step Rev Control. A Two Step allows you to set two rpm limits, one for a holeshot rpm and another for overrev protection. The 6AL is supplied with rubber shock mounts and modules for 3,000, 6,000, 7,000 and 8,000 rpm. OPERATING SPECIFICATIONS Operating Voltage: +10-18 VDC Negative Ground Current Requirements: 5 Amps-5,000 RPM / 10 Amps-10,000 RPM RPM Range: 15,000 RPM with 14.4 Volts Spark Duration: 20 Degree Crankshaft Rotation Energy Output Max: 105-115 mJ Per Spark Weight and Size: 3 lbs, 8"Lx4"Wx2.25"H Voltage Output Max: Primary: 460-480 Volts Secondary: 45,000 Volts (Blaster Coil)
