MSD Ignition

MSD 6A IGNITION CONTROL BOX
	Quantity in Basket: None Code: MSD6200 Price: $235.00 Parts In Set: EACH
	Quantity:
MSD 6A, PN 6200 The MSD 6A is the base model of the capacitive discharge multiple spark 6 Series design. Whether you have a powerful street machine, hard working truck or trick street rod, the powerful multiple sparks of the MSD 6A will ensure complete combustion. Benefits such as quicker ET's, easier starting, reduced plug fouling, more power and even increased fuel economy can be expected with the 6A's high energy multiple sparks. Like all of the MSD 6 Series Ignitions, the 6A will work with virtually any vehicle as long as it has a 12-18 volt electrical system. It can be triggered using breaker points, a magnetic pickup or the output of an electronic amplifier. All necessary parts and wiring instructions are included. OPERATING SPECIFICATIONS Operating Voltage: +10-18 VDC Negative Ground Current Requirements: 5 Amps-5,000 RPM / 10 Amps-10,000 RPM RPM Range: 15,000 RPM with 14.4 Volts Spark Duration: 20 Degree Crankshaft Rotation Energy Output Max: 105-115 mJ Per Spark Weight and Size: 2.75 lbs, 8"Lx3.5"Wx2.25"H Voltage Output Max: Primary: 460-480 Volts Secondary: 45,000 Volts (Blaster Coil)

Code	Name	Image	Price
MSD3193	MSD SPARK PLUG WIRES, 8.0MM BLUE, FOR USE WITH MSD DISTRIBUTOR		$42.00
MSD31939	MSD SPARK PLUG WIRES, 8.5MM RED, FOR USE WITH MSD DISTRIBUTOR		$61.00
MSD6420	MSD 6AL IGNITION CONTROL BOX		$285.00
MSD8202	MSD COIL, BLASTER 2, FOR USE WITH IGNITION CONTROL BOX		$45.00
MSD8203	MSD COIL, BLASTER 2, WITH BALLAST FOR IGNITION WITH POINTS		$46.00
MSD8222	MSD COIL, BLASTER 2, HIGH-VIBRATION		$60.00
MSD8434	MSD REPLACEMENT CAP FOR MSD #8485 BILLET DISTRIBUTOR		$20.00
MSD8470	MSD REPLACEMENT ROTOR FOR MSD #8485 BILLET DISTRIBUTOR		$10.00
MSD8485	MSD BILLET DISTRIBUTOR		$260.00
